Single Compression

Single Compression
BALING CHAMBER	12”× 16” × 44” (WxHxL)
BALE SIZE	15” × 15”x8-10(HxWxL)
ELECTRIC MOTOR	15 HP 3 PHASE 1440 RPM
HYDRAULIC DRIVE	PLUNGERA PUMP
HYDRAULIC OIL	HYDROL/ENCLO -68
FORCE ON MAIN CYLINDER – PISTON	75 TONS
WORKING PRESSURE	1.5 TON/INCH²
WEIGHT OF THE BALE	20-35 Kgs (Approx) (in MS)
IDLE CYCLE TIME	90-95 Seconds (Approx)
WEIGHT OF THE MACHINE	2.75 Tons (Approx)
OIL TANK CAPACITY	250Lts
HARD LINER PLATES	OPTIONAL
